Vertical Turning Lathe



The DKCK-DL 5 is a high-speed, high-rigidity inverted vertical turning lathe engineered for high-volume mass production.







Technical Parameter Item	Specifications & Capabilities
Max. Swing Diameter	Ø 450 mm
Max. Workpiece Diameter	Ø 300 mm
Max. Workpiece Length	200 mm
Max. Spindle Speed	4,000 r/min
X / Z Axis Travel	590 mm / 250 mm
X / Z Axis Rapid Traverse	15–20 m/min
Repeat Positioning Accuracy	0.003 mm
Spindle Run-Out	0.005 mm
Feedback Resolution	0.001 mm (Grating absolute measurement)
CNC Control System	SIEMENS 828D

Typical Applications:Bearing rings, flanges, small housings, automotive components, and other high-volume turned parts.







Inverted Pick-Up Spindle: Spindle moves along the axis to pick up and clamp parts directly from the infeed system, reducing the need for external loading equipment.



Meehanite Cast Iron StructureL: Rigid one-piece base designed to maintain stability during high-speed cutting and continuous operation.



Slant Bed Design: Inclined structure allows chips and coolant to flow away from the machining area, helping maintain a clean cutting environment.







Reduced Non-Cutting Time: Integrated part pick-up mechanism shortens loading and unloading cycles, improving overall machine utilization.



Stable Batch Production: Consistent positioning and rigid structure support reliable dimensional control across large production volumes.



Cleaner Machining Process: Vertical orientation allows chips to fall away naturally, reducing chip accumulation and secondary cutting.







Gripper & Chuck Customization: Tailored pick-up jaws designed around specific forging or casting geometries.



Part Conveyor Layouts: Tailored accumulation conveyor belts or stacking units designed to fit your shop floor layout.



In-Process Gauging: Post-process probing systems for automatic tool-wear compensation and real-time part verification.







CE certified and manufactured under ISO 9001:2015 standards. Each machine undergoes laser calibration, accuracy verification, and continuous operation testing before delivery. Inspection reports and test data are provided with shipment.





Warranty: 12-month coverage for major mechanical and electrical components.



Installation & Training: On-site support for machine setup, alignment, and operator training.



Remote Support: CNC system supports remote diagnostics for troubleshooting and maintenance.





MOQ	1 Unit
Lead Time	60–70 days from final approved engineering prints and deposit receipt.
Packaging	Sea-worthy heavy-duty steel base mounting with anti-rust vacuum barrier sealing, fully enclosed within a reinforced export wooden box.
Shipping	Transported via flat-rack or open-top container depending on the custom layout of the infeed/outfeed material lines.
