Lathe Automation

Lathe Automation integrates CNC turning machines with automatic loading and unloading systems, including robotic arms, gantry loaders, and bar feeders.

Engineered for industrial environments where uptime and predictability are critical, this system supports continuous, unmanned operations for:

• Stable mass production and 24/7 lights-out manufacturing
• Reduced operator dependency and lower labor risk
• Consistent machining accuracy across high-volume batches
• Seamless integration into existing automated production lines

Built with genuine Japanese THK linear guides and Yaskawa servo systems to maintain a tested repeatability within 0.02mm.

Employs standard EtherCAT and Profinet protocols for direct, dual-channel communication with FANUC, Siemens, Mitsubishi, and Haas CNC controllers.

Lowers part changeover and loading cycle times to approximately 6–8 seconds to directly optimize overall equipment effectiveness (OEE).

Features integrated Omron safety light curtains and active collision sensors designed to align with international ISO 13849-1 (PLd) safety standards.

Accommodates shafts, discs, and rings through fully adjustable matrix trays and customizable pneumatic or servo gripper configurations.

To fit varying workshop layouts and part geometries, our lathe automation systems are available in three proven configurations:

Truss Gantry Loaders (Overhead Automation)
Best For: High-volume, standardized shaft and disc processing.

Advantage: Overhead mounting saves valuable factory floor space and leaves the front of the lathe completely accessible for manual tool changes or maintenance.

Articulated Robotic Cells (Floor-Mounted)
Best For: High-mix, low-volume (HMLV) production and multi-process handling.

Advantage: Maximum flexibility. The robotic arm can perform secondary tasks such as part flipping, air-blasting, post-process gauging, and deburring.

Integrated Bar Feeder Systems
Best For: Continuous machining of bar stock and small hardware components.

Advantage: Heavy-duty, vibration-dampening design ensuring high-speed turning stability.

3-Day CAD Layouts: Customized 2D/3D floor plan layouts based on your lathe dimensions are provided by our engineers within 3 business days.

Full Documentation: Complete English manuals, electrical schematics, and I/O mapping are supplied with every order to simplify local integration.

72-Hour Simulation Test: Every unit undergoes a mandatory 72-hour continuous, full-load simulation run before dispatch, with a verified test report included. (Sample test reports and dynamic video proofs are available upon request to your sales engineer.)

Component Traceability: Built exclusively with traceable, industry-standard components from recognized brands for easier local maintenance.
